Engine-Aircleanersandlines
Airintakesystem-Removefrom7230
1.Removetherearleftendshield(1)bypullingoutand
liftingup.Thispanelissecuredbytwoballstudslo-
catedoncoverframethatlatchontotwospringclips
ontheshield.
NHPE13AF00440AA1
2.Removetheconnectorfromtherestrictionsensor(1)
ontheairintaketube(2).
NHPE13AF00542AA2
3.Removetheharnessconnector(1)fromthepressure
switch(2)ontheairlterhousing.
NHPE13AF00543AA3
4804083715/08/2017
10.1[10.202]/9
