STEP 16
MK99J018
Remove the mounting bolt and nut. Remove the A/C
suction and dryer hoses from the hose bracket.
STEP 17
MK98G023
Turn the valve lever clockwise to shut off the fuel
valve on the tank.
STEP 18
MK99J017
Install clamps on the fuel supply and return hoses.
Loosen the hose clamps and remove the hoses from
the engine. Cap the fuel pump fittings and plug the
hose ends.
STEP 19
MK99J028
Remove the engine front frame wire harness
connector from the engine wire harness.
STEP 20
MK99J022
Open the cover plug (1) and remove the Phillips head
screw to remove the starter switch wire (2) from the
starter solenoid.
STEP 21
MK99J021
Remove the battery cable, alternator cable and
starter switch power supply wire from the starter
solenoid.
1
2
