ENGINE REMOVAL
STEP 1
1. Park the tractor on a hard level surface.
2. Place the shift lever in PARK (Powershift) or
place the shift levers in neutral.
3. Shut off the engine and remove the key from the
switch.
4. If necessary, drain the oil from the engine
crankcase.
STEP 2
See Section 9007 for instructions to remove the hood
from the tractor.
STEP 3
See Section 9001 for instructions to discharge the air
conditioning system.
STEP 4
See Section 9008
for instructions to drain and remove the radiator and
cooler assembly.
STEP 5
MD02A202
Open the battery access door and remove the
negative battery cables from the three batteries.
STEP 6
MD02A200
Remove the front two hoses from the deaeration
tank.
STEP 7
MD02A201
Remove the overflow hoses from the deaeration
tank.
Remove the clamp from the hood support bracket.
STEP 8
MD02A203
Remove the engine to deaeration tank hose.
To Next Page
