STEP 9
MD02A204
MD02A205
Remove the LH (1) and RH (2) hood support
mounting bolts, washers and nuts. Remove the hood
support from the tractor.
STEP 10
MD02A206
Remove the two A/C suction hose clamps from the
engine.
STEP 11
MD02A207
Remove the suction hose and high pressure hose
from the A/C compressor. Install caps on the
compressor ports and plugs in the hose ends.
STEP 12
MD02A208
Remove the upper radiator hose.
STEP 13
MD02A188
Remove the lower radiator hose.
1
2
