STEP 77
MD02A207
Install the high pressure (1) and suction (2) hoses on
the A/C compressor.
STEP 78
MD02A206
Install the two A/C suction hose clamps on the
engine.
STEP 79
MD02A188
Install the lower radiator hose.
STEP 80
MD02A204
MD02A205
Install the hood support and deaeration tank over the
engine. Install the LH (1) and RH (2) mounting bolts,
washers and nuts. Tighten the bolts and nuts to
specifications.
STEP 81
MD02A203
Install the deaeration tank to engine hose. Tighten
the clamps.
2
1
2
1
