INTRODUCTION
3.Disconnectthenegativebatterycablefromtheneg-
ativebatteryterminal.
RCPH11TLB003AAM3
Masterdisconnectswitch(ifequipped)
Enableordisableelectricalpowerfromthemachinebat-
teriestotheelectricalcomponentsusingthemasterdis-
connectswitch,locatedontherighthandsideoftheen-
gine.
NOTICE:Waitatleast60secondsafterignitionkeyis
placedintheOFFpositionbeforeturningmasterdiscon-
nectswitchtoOFF .Thisallowsthemachinecontrollersto
shutdownproperly.
NOTICE:Somemachineserviceproceduresrequirean
actualterminaldisconnectofthebatteries.Donotusethe
masterdisconnectforthosetypesofprocedures,suchas
weldingonthemachine.
RCPH11TLB002BAD4
4744159427/09/2012
