Case 570NXT - Welding Safety Preparations

INTRODUCTION
BasicinstructionsWeldingonthemachine
Contactyourdealerifyouhaveanyquestionsbeforeweldingonthismachine.Thefollowingproceduresmustbe
completedbeforewelding.
Removethebatterycoveranddisconnectthebatteries.
RCPH10TLB429AAF1
Disconnectthealternatorterminalwires.
RCPH11TLB005BAD2
Disconnecttheenginecontrolunit(ECU)
1.Removethecoverfromthesteeringcolumnshroud.
RAPH12UTL0128AA3
2.RemovetheECUguardplate.
3.DisconnectbothECUconnectors.
4744159427/09/2012
18
