Case 570NXT - Loader Lift Arm Support Procedure

INTRODUCTION
BasicinstructionsLoaderliftarm
WARNING
Crushinghazard!
Ifyouservicethemachinewiththeloaderliftarmsraised,alwaysusethesupportstrut.Removethe
retainingpinandplacethesupportstrutontothecylinderrod.Installtheretainingpinintothesupport
strut.Lowertheliftarmsontothesupportstrut.
Failuretocomplycouldresultindeathorseriousinjury.
W0230A
Raiseandsupportloaderliftarms:
1.Emptytheloaderbucket.
2.Raisetheloaderliftarmstothemaximumheight.
3.Shutdowntheengine.
RCPH10TLB230AAF1
4.Removetheretainingpin.
5.Lowerthesupportstrutontothecylinderrod.
6.Installtheretainingpin.
RCPH10TLB221AAF2
7.Starttheengine.
8.Slowlylowertheliftarmssothattheendofthesup-
portstrutrestsonthecylinder.
RCPH10TLB227AAF3
4744159427/09/2012
21
