INTRODUCTION
Disconnecttheinstrumentcluster.
1.Removetheinstrumentclusterpanel.
2.Disconnectallconnectorsfromthebackofthe
panel.
RAIL12FRK1169FA4
•
Disconnectthecontrollerfortheloader4in1bucket
orauxiliaryhydraulics,ifequipped(oneconnector,
locatedundertheloadervalveattherear,leftun-
dersideofthemachine).
