Engine-Engineandcrankcase
Engine-Generalspecication
Model
Diesel,F5HFL413D*A
TypeFourcylinder,turbocharged
Firingorder1-3-4-2
Boreandstroke
99mmx110mm(3.9inx4.33in)
Displacement
3.4l(207in³)
Compressionratio
16.5to1
Fuelinjection
DirectHPCR
Horsepower-ratedat2200RPM
Gross
Netwith39°fan
63kW(85Hp)
58kW(79Hp)
Peaktorqueat1400RPM
Gross
Netwith39°fan
Maximumtorquerise
374N·m(276lbft)
364N·m(268lbft)
36%±5RPM
Engine-Speedsstalltestchecksheet
Resultsfromstalltestprocedure(llinvaluesaccordingly)
IDRPMtestvalve
Stalltestcomponent(speciedvalue)
1
Loaderhydraulicstallspeed(2200-2330RPM)
2
Torqueconverterstallspeed(2150-2310RPM)
3
Combined-loaderhydraulicandtorqueconverter-stallspeed(1610-1890RPM)
Stalltestreferencechart
IDRPMResults
12230to2330
22180to2310
31610to1890
AllsystemsoperatingwithinnormalspeciedRPMvalues.
1Above2330
2Above2310
3Above1890
Engineproblem.Checkenginespeeds.Refertotheengineservicemanual.
1Below2230
2Below2180
3Below1610
Engineproblem.Checkenginespeeds.Replacethefuelandairlters.Refer
totheengineservicemanual.
1Below2230
22180to2310
3Below1610
Hydraulicsystemproblem(s).Checkthesettingofthemainreliefvalve.Checkthe
outputofthehydraulicpump.
1Above2330
22180to2310
3Above1890
Hydraulicsystemproblem(s).Checkthesettingofthemainreliefvalve.Checkthe
outputofthehydraulicpump.Checkforleakageintheloadercontrolvalve.
12230to2330
22180to2310
31610to1890
Hydraulicsystemproblem(s).Checkthesettingofthemainreliefvalve.Checkthe
outputofthehydraulicpump.
12230to2330
22180to2310
31610to1890
Hydraulicsystemproblem(s).Checkthesettingofthemainreliefvalve.Checkthe
outputofthehydraulicpump.
12230to2330
2Above2310
3Above1890
Torqueconverterortransmissionproblems.
12230to2330
2Below2180
3Below1610
Torqueconverterortransmissionproblems.
