INTRODUCTION
Basicinstructions-Hydraulicdiagnostictestports
Ifequipped,themachine’shydraulicsystempressurecanbeeasilycheckedfromthehydraulicquickdisconnect
diagnostictestport(s)locatedontheright-handsideofthemachineabovethehydraulicreservoirtankandnearthe
right-handstabilizerontheinsideofthechassis.
Hydraulictestportcongurations
NOTE:Hydraulictestportsonamachinewithpilotbackhoecontrolsshownintheillustration.
NOTICE:Alwayskeepthecoversonthequickconnecttestportswhennotinuse.
Remotehydraulictestports,ifequipped
•
Topport(1)-Pumpoutputpressure
•
Bottomport(2)-Loadsense(LS)pressure
NOTE:Loadsensepressureportnotavailableonma-
chineswithmechanicalbackhoecontrols.
