Case 590SN - Basic Instructions - Hood

INTRODUCTION
Basicinstructions-Hood
WARNING
Crushinghazard!
Ifyouservicethemachinewiththeloaderliftarmsraised,alwaysusethesupportstrut.Removethe
retainingpinandplacethesupportstrutontothecylinderrod.Installtheretainingpinintothesupport
strut.Lowertheliftarmsontothesupportstrut.
Failuretocomplycouldresultindeathorseriousinjury.
W0230A
Openthehood:
1.Raisetheloaderandengagethesupportstrut.
2.Shutdowntheengine.
3.Turnthehandlecounter-clockwisetoreleasethehood
latch.
RAIL14TLB0848BA1
3.Liftthehoodandrotateforward.
RCPH10TLB356AAF2
NOTICE:Toavoiddamagetothehoodparts,alwaysclosethehoodbeforemovingtheloader.
Closethehood:
1.Lowerthehood.
2.Turnthehandleclockwisetolockthehoodlatch.
RAIL14TLB0848BA3
