7.Removetheinstrumentclusterpanelscrewsandthe
instrumentcluster.
RCPH10TLB339AAF9
8.Disconnectallconnectorsfromthebackofthepanel.
RAIL15TLB0007BA10
9.Disconnectthecontrollerforbackhoepilotcontrols,
ifequipped(oneconnector).
10.Disconnectthetransmissioncontroller,ifequipped
(oneconnector,locatedunderthefrontsteeringcowl-
ing).
11.Disconnectthecontrollerfortheloader4-in-1bucket
orauxiliaryhydraulics,ifequipped(oneconnector,lo-
catedundertheloadervalveattherear,leftunder-
sideofthemachine).
