5 - 45
ELECTRIC CIRCUIT
CASE TRAINING CENTER
AUGUST 2000
Engine fuel injection pump electronic regulator
1) Circuit configuration
CM00F010
1. Engine
2. Hydraulic system
3. Engine electronic control box
4. Main electronic control box
5. Fuel injection pump
6. Fuel flow regulating resistor
7. Electronic regulator
8. Engine speed detector
9. Throttle control
10. Starter motor switch
11. CAN connection
12. Detector and sender information input
13. Engine speed signal
14. Rack position detector signal
15. Rack control signal
16. Engine speed detector signal
1
6
5
7
8
2
12
4
11
3
16
15
14
13
9
10
