DIAGNOSTIC - SELECTION
4 - 7
CASE TRAINING CENTER
AUGUST 2000
5. Previous failures on the excavator DIAG5
Example:
The screen above shows that there is a failure in the hydraulic oil temperature sender and in the fuel level sender.
6. Previous failures on the excavator DIAG6
This screen is connected to the previous screen (DIAG5) as regards failures involving the hourmeter.
Example:
The screen above shows that failure code 0020 (hydraulic oil temperature sender) occurred at 1200 H and that
failure code 0030 occurred at 1000 H.
A. The numbers of hours shown indicate the time at which the failures occurred for the first time since the data was re-
initialised.
B. To erase the failure codes and the number of hours, press the work mode switch for 10 seconds.
C. When data is erased from screens DIAG5 and DIAG6. it is recorded in the electronic control box memory (this data
is only visible using an external computer).
DIAG MODE II H M 0000
5
M 0020 M 0000
M 0030 M 0000
M 0000 M 0000
M: Failure code
DIAG MODE II H M 0000
3
M 1200 M 0000
M 1000 M 0000
M 0000 M 0000
M: Failure code
