Case CX160B - Machine Specifications Overview; Main Data; Performance Metrics; Complete Machine Dimensions

Lep SM160B1002-1EN Issued 07-09
1002-9
SPECIFICATIONS
Main data
Model name .......................................................................................................CX160B or CX180B Hydraulic Excavator
Operating weight
CX160B ........................................................................................................................................17000 kg (37479 lbs)
CX180B ........................................................................................................................................17900 kg (39463 lbs)
Engine output...................................................................................................................................... 89.2 kW / 2200 rpm
Performance
Swing speed.....................................................................................................................................................11.5 Tr/min.
Travel speed
CX160B ...................................................................................................................... Low Speed 2.8 km/h (1.74 mph)
CX180B ...................................................................................................................... Low Speed 2.3 km/h (1.43 mph)
CX160B ......................................................................................................................High Speed 5.4 km/h (3.35 mph)
CX180B ......................................................................................................................High Speed 4.0 km/h (2.48 mph)
Maximum drawbar pull
CX160B .......................................................................................................................................161 kN (36194.24 lbf)
CX180B ......................................................................................................................................... 190 kN (42713.7 lbf)
Grade ability........................................................................................................................................................70% (35°)
Ground pressure
CX160B ........................................................................................................47 kPa (500 mm (19.68 in) grouser shoe)
CX160B/CX180B..........................................................................................40 kPa (600 mm (23.62 in) grouser shoe)
CX160B/CX180B..........................................................................................35 kPa (700 mm (27.56 in) grouser shoe)
CX180B ........................................................................................................31 kPa (800 mm (31.50 in) grouser shoe)
Complete machine dimensions
CX160B (Standard boom)
Arm (dipper)
2620 mm
(103.15 in)
2220 mm
(87.40 in)
3050 mm
(120.08 in)
Lenght (without attachment)
4410 mm
(173.62 in)
4410 mm
(173.62 in)
4410 mm
(173.62 in)
Lenght (with attachment)
8440 mm
(332.22 in)
8490 mm
(334.25 in)
8520 mm
(335.43 in)
Height (with attachment)
2960 mm
(116.53 in)
3000 mm
(118.11 in)
3130 mm
(123.23 in)
CX160B (Articulated boom)
Arm (dipper)
2620 mm
(103.15 in)
2220 mm
(87.40 in)
3050 mm
(120.08 in)
Lenght (without attachment)
4410 mm
(173.62 in)
4410 mm
(173.62 in)
4410 mm
(173.62 in)
Lenght (with attachment)
8330 mm
(327.95 in)
8365 mm
(329.33 in)
8365 mm
(329.33 in)
Height (with attachment)
2950 mm
(116.14 in)
2950 mm
(116.14 in)
3025 mm
(119.09 in)
CX180B
Arm (dipper)
2620 mm
(103.15 in)
2220 mm
(87.40 in)
3050 mm
(120.08 in)
Lenght (without attachment)
4500 mm
(177.17 in)
4500 mm
(177.17 in)
4500 mm
(177.17 in)
Lenght (with attachment)
8440 mm
(332.22 in)
8490 mm
(334.25 in)
8520 mm
(335.43 in)
Height (with attachment)
2960 mm
(116.53 in)
3000 mm
(118.11 in)
3120 mm
(122.83 in)
