2. SPECIFICATIONS
2-9
2
2. ARM & BUCKET (Japanese standard bucket)
3. ARM
4. BUCKET (Japanese standard bucket)
L X H X W
mm (ft-in)
1,750 X 350 X 450
(5'8.9" X 1'1.8" X 1'5.7")
Weight kg (lbs) 100 (221)
L X H X W
mm (ft-in)
1,260 X 330 X 250
(4'1.6" X 1'1.0" X 9.8")
Weight kg (lbs) 61 (135)
Heaped capacity
m
3
(cu-yd)
0.044 (0.058)
L X H X W
mm (in)
550 X 440 X 450
(1'9.6" X 1'5.3" X 1'5.7")
Weight kg (lbs) 35 (77)
L
H
L
H
L
H
