Case CX180C - Page 35

INTRODUCTION
Boomcylinder
Stroke1179mm(46.417in)
Weight
157kg(346.128lb)
Armcylinder
ManufacturerKYBCorporation
Cylinderbore∅125mm(4.921in)
Roddiameter
∅90mm(3.543in)
Maximumretractedlength
1830mm(72.047in)
Stroke1280mm(50.394in)
Weight
201kg(443.131lb)
Bucketcylinder
ManufacturerKYBCorporation
Cylinderbore∅105mm(4.134in)
Roddiameter
∅75mm(2.953in)
Maximumretractedlength
1507mm(59.331in)
Stroke985mm(38.780in)
Weight
117kg(257.942lb)
4813907019/04/2017
28
