Case CX180C - Main Equipment Specifications; Lower Component Specifications

INTRODUCTION
Generalspecication-Mainequipment
Lowercomponent
Travelunit
ManufacturerKYBCorporation
MotortypeVariabledisplacementpistonmotor
Automatic2-speedswitchoverwithparkingbrake
Intakeamount
72.8cm³/rev(4.44in³/rev)/143.5cm³/rev(8.76in³/rev)
Operatingpressure34.3MPa(4975psi)
Operatingow143.0L/min(37.8USgpm)
Braketorque
25100N·m(18513lbft)min.(includingreductiongear)
Reliefvalvesetpressure35.3MPa(5120psi)at40l/min(10.57USgpm)
Automatic2-speedswitchoverpressure
25.8MPa(3742psi)/26.5MPa(3844psi)
Reductiongear
ReductiongeartypePlanetarygear2-stagereductiongear
Reductionratio43.246
Dryweight
260kg(573.202lb)
Take-uproller
Weight
96.4kg(212.5256lb)
Upperroller
Weight
17.8kg(39.2423lb)
Lowerroller
Weight
35.5kg(78.2641lb)
Recoilspring
Yoke(Quantity1)23.9kg(52.6908lb)
SemsBM16x50(Quantity4)0.1kg(0.2205lb)
Threadedrod(Quantity1)21.9kg(48.2812lb)
GrooveheightNM48(Quantity1)1.0kg(2.2046lb)
SPpin8x80(Quantity1)0.1kg(0.2205lb)
Recoilspring(Quantity1)39.4kg(86.8626lb)
Greasecylinderassembly(Quantity1)28.4kg(62.6116lb)
SemsBM16x55(Quantity2)0.1kg(0.2205lb)
Assembly(total)115.3mm(254.1943in)
Mountinglengthofspring478mm(18.819in)
Shoe
WeightorQuantity
500grouser
1071kg(2361.163lb)
Link1set
Shoe
44
Bolt176
Nut176
600grouser
1181.02kg(2603.703lb)
Link1set
Shoe
44
Bolt176
Nut176
700grouser
1391kg(3066.646lb)
Link1set
Shoe
44
Bolt176
4813907019/04/2017
22
