Case CX180C - Dimensions; Standard Arm Dimensions

INTRODUCTION
Dimensions
[2.23m(7.3163ft)]Arm[2.62m(8.5958ft)]Arm
[3.05m(10.0066ft)]
Arm
Overalllength(withoutattachment)4410mm(173.622in)4410mm(173.622in)4410mm(173.622in)
Overalllength(withattachment)8740mm(333.465in)8440mm(332.283in)8500mm(334.646in)
Overallheight(totopofboom)3000mm(118.110in)2960mm(116.535in)3130mm(123.228in)
Overallheight(totopofguardrail)3080mm(121.260in)3080mm(121.260in)3080mm(121.260in)
Cabheight2940mm(115.748in)2940mm(115.748in)2940mm(115.748in)
Upperstructureoverallwidth
2540mm(100.000in)2540mm(100.000in)2540mm(100.000in)
Swing(rearend)radius2450mm(96.457in)2450mm(96.457in)2450mm(96.457in)
Clearanceheightunderupper
structure
1020mm(40.157in)1020mm(40.157in)1020mm(40.157in)
Minimumgroundclearance420mm(16.535in)420mm(16.535in)420mm(16.535in)
Wheelbase(Centertocenterof
wheels)3190mm(125.591in)3190mm(125.591in)3190mm(125.591in)
Crawleroveralllength3990mm(157.087in)3990mm(157.087in)3990mm(157.087in)
Trackgauge1990mm(78.346in)1990mm(78.346in)1990mm(78.346in)
Undercarriageoverallwidth[with
600mm(23.622in)shoes]2590mm(101.969in)2590mm(101.969in)2590mm(101.969in)
Crawlertracksheight920mm(36.220in)920mm(36.220in)920mm(36.220in)
Workingranges
[2.23m(7.3163ft)]Arm[2.62m(8.5958ft)]Arm
[3.05m(10.0066ft)]
Arm
Boomlength
5150mm(202.756in)5150mm(202.756in)5150mm(202.756in)
Bucketradius
1390mm(54.724in)1390mm(54.724in)1390mm(54.724in)
Bucketwristaction
178°178°178°
MaximumreachatGRP
8500mm(334.646in)8870mm(349.213in)9220mm(362.992in)
Maximumreach
8670mm(341.339in)9040mm(355.906in)9380mm(369.291in)
Max.diggingdepth
5660mm(222.835in)6060mm(238.583in)6490mm(255.512in)
Max.diggingheight
9010mm(354.724in)9240mm(363.780in)9290mm(365.748in)
Max.dumpingheight
6380mm(251.181in)6610mm(260.236in)6690mm(263.386in)
4813907019/04/2017
21
