INTRODUCTION
Polycarbonateroofhatchandsunshade
Raindeector
Sunvisor
Autoair-conditioner
TopguardOPGlevel1(inCABstructure)
Roll-overprotectivestructure(ROPS)
Operator'sseat
KAB835:Lowfrequencymechanicalsuspensionwithhelicalspringsanddoubleactinghydraulicdamper.
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
Seatheightadjustment
Adjustablepivotingarmrests
AdjustableheadrestRetractableseatbelt
Others
Rearviewmirror(Cabsideandrightside)
Rearandrightsideviewcamera
Undercarriage
Travelmotor
Variabledisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
5.4km/h(3.355mph)(Automatictravelspeedshifting)
Travelspeeds
Low
2.8km/h(1.740mph)
Drawbarpull160kN(35969.431lb)
Numberofcarrierrollers(eachside)
2
Numberofcarrierrollers(eachside)
7
Numberofshoes(eachside)
44
Typeofshoe
Triplegrousershoe
Linkpitch190mm(7.480in)
Widthofshoe
600mm(23.622in)(S.T.D)
Grade-ability70%(35°)
Mass
Operatingmass17500kg(38581.097lb)
with2.62m(8.5958ft)Arm,0.62m³Bucket,600mm(23.622in)grousershoe,operator,lubricant,coolant
andfullfueltank
Shippingmass16700kg(36817.20lb)
Operatingmass-(operatormass[75kg(165.35lb)])+90%offuelmass[224kg(493.835lb)]+bucket
mass[498kg(1097.908lb)])
Counterweightmass3400kg(7495.72lb)
Groundpressure
0.041MPa(5.9472psi)
with2.62m(8.5958ft)Arm,0.62m³Bucket,600mm(23.622in)grousershoe
Diggingforce(with0.5m³Bucket)(ISO6015)
[2.23m(7.3163ft)]Arm[2.62m(8.5958ft)]Arm[3.05m(10.0066ft)]Arm
Armdiggingforce90kN(20236.27lb)79kN(17759.91lb)72kN(16189.01lb)
Withautopowerup95kN(21360.51lb)84kN(18883.95lb)77kN(17313.25lb)
Bucketdiggingforce112kN(25178.60lb)112kN(25178.60lb)112kN(25178.60lb)
Withautopowerup118kN(26527.46lb)118kN(26527.46lb)118kN(26527.46lb)
