Case CX180C - Dimension

INTRODUCTION
Dimension
Standardarm[2.62m(8.5958ft)]
NOTE:Numbersaresubjecttochangewithoutnoticeduetodesignchangeorotherreason.
Thediagramsgivevaluesthatincludetheshoelugheight“a”[26mm(1.024in)].
SMIL17CEX2032FA1
NOTE:Allthedimensionsingureareinmm(in).
b.
1020mm(40.157in)
e.
420mm(16.535in)
c.
1990mm(78.346in)
f.
1290mm(50.787in)
d.
600mm(23.622in)
g.
1250mm(49.213in)
4813907019/04/2017
31
