Case CX180C - Long Arm Dimensions

INTRODUCTION
Longarm[3.05m(10.0066ft)]
NOTE:Numbersaresubjecttochangewithoutnoticeduetodesignchangeorotherreason.
Thediagramsgivevaluesthatincludetheshoelugheight“a”[26mm(1.024in)].
SMIL17CEX2034FA3
NOTE:Allthedimensionsingureareinmm(in).
b.
1020mm(40.157in)
e.
420mm(16.535in)
c.
1990mm(78.346in)
f.
1290mm(50.787in)
d.
600mm(23.622in)
g.
1250mm(49.213in)
