Case CX250C - Remove

Engine-Engineandcrankcase
Engine-Remove
1.TurnOFFthebatterydisconnectswitchordisconnect
thenegativeterminalofthebattery.
•
Afterdisconnectingterminalsorharnesses,fasten
themsothattheydonotinterferewiththeframe.
Also,coverwitharubbercaptoprotectagainst
sparks.
2.Removethecounterweight.(Fordetails,See"Coun-
terweight-Remove(39.140)").
3.Removethepump.(Fordetails,See"Pump-Remove
(35.106)").
4.Useawrenchtoremovethebolts(1)and(2),andthen
removethefanshroud(3).
LPIL12CX00144BB1
5.Useawrenchtoremovethebolts(1),andthenremove
thefanguard(2).
LPIL12CX00145AB2
