Case CX250C - General Specification - Main Equipment

INTRODUCTION
Generalspecication-Mainequipment
Lowercomponent
Travelunit
ManufacturerKYBCorporation
MotortypeVariabledisplacementpistonmotor
Automatic2-speedswitchoverwithparkingbrake
Intakeamount
181.3cm³/rev(11.06in³/rev)
Operatingpressure34.3MPa(4975psi)
Operatingow234.0l/min(234.0000USgpm)
Braketorque
32700N·m(24118lbft)min.(includingreductiongear)
Reliefvalvesetpressure35.3MPa(5120psi)at40l/min(10.57USgpm)
Automatic2-speedswitchoverpressure
25.8MPa(3742psi)
Reductiongear
ReductiongeartypePlanetarygear2-stagereductiongear
Reductionratio43.246
Dryweight
271kg(597.453lb)
Take-uproller
Weight
104.3kg(229.9421lb)
Upperroller
Weight
17.8kg(39.2423lb)
Lowerroller
Weight
39.5kg(87.0826lb)
Recoilspring
ItemWeight
Quantity
Yoke
23.9kg(52.6905lb)
1
SemsBM16X500.1kg(0.2205lb)
4
Threadedrod
28.5kg(62.8317lb)
1
GrooveheightNM481.3kg(2.8660lb)
1
SPpin8x800.1kg(0.2205lb)
1
Recoilspring
64.6kg(142.4186lb)
1
Greasecylinderassembly32.8kg(72.3116lb)
1
SemsBM16X600.2kg(0.4409lb)
2
Assembly(total)152mm(5.984in)
Mountinglengthofspring576mm(22.68in)
Shoe
WeightorQuantity
600grouser
1470kg(3240.795lb)
Link1set
Shoe
51
Bolt204
Nut204
700grouser
1612kg(3553.852lb)
Link1set
Shoe
51
Bolt204
Nut204
800grouser
1760kg(3880.136lb)
Link1set
Shoe
51
