INTRODUCTION
Overalllength(withattachment)9930mm(390.945in)9980mm(392.913in)9910mm(390.157in)
Overallheight(withattachment)3150mm(124.016in)3310mm(130.315in)3310mm(130.315in)
Cabheight(totopofheadguard)3000mm(118.110in)3000mm(118.110in)3000mm(118.110in)
Overallheight(totopofguardrail)3180mm(125.197in)3180mm(125.197in)3180mm(125.197in)
Upperstructureoverallwidth
2770mm(109.055in)2770mm(109.055in)2770mm(109.055in)
Swing(rearend)radius2950mm(116.142in)2950mm(116.142in)2950mm(116.142in)
Clearanceheightunderupper
structure
1100mm(43.307in)1100mm(43.307in)1100mm(43.307in)
Minimumgroundclearance440mm(17.323in)440mm(17.323in)440mm(17.323in)
Wheelbase(Centertocenterof
wheels)3840mm(151.181in)3840mm(151.181in)3840mm(151.181in)
Crawleroveralllength4650mm(183.071in)4650mm(183.071in)4650mm(183.071in)
Trackgauge2590mm(101.969in)2590mm(101.969in)2590mm(101.969in)
Undercarriageoverallwidth[with
600mm(23.622in)shoes]3190mm(125.591in)3190mm(125.591in)3190mm(125.591in)
Crawlertracksheight940mm(37.008in)940mm(37.008in)940mm(37.008in)
Workingranges
[3.00m(9.8425ft)]Arm[2.50m(8.2021ft)]Arm[3.50m(11.4829ft)]
Boomlength
5850mm(230.315in)5850mm(230.315in)5850mm(230.315in)
Bucketradius
1580mm(62.205in)1580mm(62.205in)1580mm(62.205in)
Bucketwristaction
175°175°175°
MaximumreachatGRP
10100mm(397.638in)9630mm(379.134in)10620mm(418.110in)
Maximumreach
10280mm(404.724in)9820mm(386.614in)10790mm(424.803in)
Max.diggingdepth
6900mm(271.654in)6400mm(251.969in)7420mm(292.126in)
Max.diggingheight
9760mm(384.252in)9560mm(376.378in)10070mm(396.457in)
Max.dumpingheight
6760mm(266.142in)6550mm(257.874in)7060mm(277.953in)
