INTRODUCTION
Polycarbonateroofhatch&Sunshade
Autoair-conditioner
Raindeector
Sunvisor
TopguardOPGlevel1(inCABstructure)
Roll-overprotectivestructure(ROPS)
Operator'sseat
KAB835:Lowfrequencymechanicalsuspensionwithhelicalspringsanddoubleactinghydraulicdamper.
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
SeatheightadjustmentAdjustablepivotingarmrestslinkedtoconsoles
Adjustableheadrest
Retractableseatbelt
Others
Rearviewmirror(Cabside&Rightside)
Rear&RightsideviewCamera
Undercarriage
Travelmotor
Variabledisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
5.5km/h(3.42mph)(Automatictravelspeedshifting)
Travelspeeds
Low
3.5km/h(2.175mph)
Drawbarpull201kN(45186.60lb)
Numberofcarrierrollers(eachside)
2
Numberofcarrierrollers(eachside)
9
Numberofshoes(eachside)
51
Typeofshoe
Triplegrousershoe
Linkpitch190mm(7.480in)
Widthofshoe
600mm(23.622in)(S.T.D)
Grade-ability70%(35°)
Mass
Operatingmass25300kg(55776.952lb)
with3.00m(9.8425ft)Arm,1.1m³Bucket,600mm(23.622in)grousershoe,operator,lubricant,coolant
andfullfueltank
Shippingmass24000kg(52910.943lb)
Operatingmass-(operatormass[75kg(165.35lb)])+90%offuelmass+bucketmass[960kg(2116.4lb)])
Counterweightmass5400kg(11904.962lb)
Groundpressure
0.05MPa(7.25250psi)
with3.00m(9.8425ft)Arm,1.1m³Bucket,600mm(23.622in)grousershoe
Diggingforce(with1.1m³Bucket)(ISO6015)
[3.00m(9.8425ft)]Arm[2.50m(8.2021ft)]Arm
[3.50m(11.4829ft)]
Arm
Armdiggingforce120kN(26977.07lb)141kN(31698.06lb)107kN(24054.56lb)
Withautopowerup129kN(29000.35lb)151kN(33946.15lb)115kN(25853.03lb)
Bucketdiggingforce162kN(36419.05lb)162kN(36419.05lb)162kN(36419.05lb)
Withautopowerup174kN(39116.76lb)174kN(39116.76lb)174kN(39116.76lb)
Dimensions
[3.00m(9.8425ft)]Arm[2.50m(8.2021ft)]Arm[3.50m(11.4829ft)]
Overalllength(withoutattachment)5270mm(207.480in)5270mm(207.480in)5270mm(207.480in)
