INTRODUCTION
Arm-inforcedregenerativecircuit
Swingpriorityvariableorice(forarmoperation)
2pumpsow
Variablefootrelief
Weight
199kg(438.720lb)
Solenoidvalve(5stack)
ManufacturerYukenKogyoCo.,Ltd.
Valvespecications
MaximumowP→B25l/min(6.604USgpm)Other5l/min(1.321USgpm)
Ratedpressure
4.5MPa(652psi)
PortsizeP .T.Bport
G3/8
C1,C2,C3,C4,C5portsG1/4
Solenoidspecications
OperatingvoltageDC20-32V
Powerconsumption17Wmax.
Weight
6.7kg(14.7710lb)
Valveforleft/rightoperations
Manufacturer
KawasakiHeavyIndustries,Ltd.
Operatingpressure3.92MPa(569psi)
Secondarypressure0.64-2.45MPa(92.8320-355psi)primaryshorttype
1,3port
19°
Operatingangle
2,4port
25°
Weight
1.9kg(4.1888lb)
Valvefortraveloperation
Manufacturer
KawasakiHeavyIndustries,Ltd.
Operatingpressure3.92MPa(569psi)
Secondarypressure0.64-2.45MPa(92.8320-355psi)primaryshorttype
Operatingangle12.4°
Weight
5.5kg(12.1254lb)
Remotecontrolvalveforoptionoperations
ManufacturerNishinaIndustrialCo.,Ltd.
Operatingpressure39.2bar(568.400psi)
Secondarypressure6.4-24.5bar(92.800-355.250psi)primaryshorttype
Operatingangle11.4°–12.6°
Portsize
P ,T,A,B,C1,C2G1/4
Weight
1.7kg(3.748lb)
