Case CX490C - Page 28

INTRODUCTION
Dimensions
[2.53m(8.3005ft)]HD
Arm
[3.13m(10.2690ft)]
HDArm
[3.38m(11.0892ft)]
HDArm
Overalllength(withoutattachment)6270mm(246.850in)6270mm(246.850in)6270mm(246.850in)
Overalllength(withattachment)12110mm(476.772in)12110mm(476.772in)12070mm(475.197in)
Overallheight(withattachment)3650mm(143.701in)3720mm(146.457in)3630mm(142.913in)
Cabheight(totopofheadguard)3440mm(135.433in)3440mm(135.433in)3440mm(135.433in)
Overallheight(totopofguardrail)3660mm(144.094in)3660mm(144.094in)3660mm(144.094in)
Upperstructureoverallwidth(without
catwalks)3060mm(120.472in)3060mm(120.472in)3060mm(120.472in)
Upperstructureoverallwidth(with
catwalks)3590mm(141.339in)3590mm(141.339in)3590mm(141.339in)
Swing(rearend)radius3730mm(146.850in)3730mm(146.850in)3730mm(146.850in)
Clearanceheightunderupper
structure
1330mm(52.362in)1330mm(52.362in)1330mm(52.362in)
Minimumgroundclearance540mm(21.260in)540mm(21.260in)540mm(21.260in)
Wheelbase(Centertocenterof
wheels)4040mm(159.055in)4040mm(159.055in)4040mm(159.055in)
Crawleroveralllength5100mm(200.787in)5100mm(200.787in)5100mm(200.787in)
Trackgauge2750mm(108.268in)2750mm(108.268in)2750mm(108.268in)
Undercarriageoverallwidth[with
600mm(23.622in)shoes]3350mm(131.890in)3350mm(131.890in)3350mm(131.890in)
Crawlertracksheight1240mm(48.819in)1240mm(48.819in)1240mm(48.819in)
Workingranges
[2.53m(8.3005ft)]HD
Arm
[3.13m(10.2690ft)]
HDArm
[3.38m(11.0892ft)]
HDArm
Boomlength
6980mm(274.803in)6980mm(274.803in)6980mm(274.803in)
Bucketradius
1860mm(73.228in)1860mm(73.228in)1860mm(73.228in)
Bucketwristaction
176°176°176°
MaximumreachatGRP
11010mm(433.465in)11590mm(456.299in)11800mm(464.567in)
Maximumreach
11250mm(442.913in)11820mm(465.354in)12020mm(473.228in)
Max.diggingdepth
6890mm(271.260in)7500mm(295.276in)7750mm(305.118in)
Max.diggingheight
10820mm(425.984in)11140mm(438.583in)11150mm(438.976in)
Max.dumpingheight
7400mm(291.339in)7690mm(302.756in)7720mm(303.937in)
4809839920/01/2017
21
