Case CX490C - Dimension

INTRODUCTION
PortB
ForwardleftG1
PortC
Backwardright
G1
PortD
BackwardleftG1
PortTDrainport
G1/2
PortPPilotport
G1/4
Weight
55.5kg(122.357lb)
Backhoeattachment
Cylinder
Boomcylinder
Cylinderbore∅ 170mm(6.693in)
Roddiameter
∅ 115mm(4.528in)
Maximumretractedlength
2230mm(87.795in)
Stroke1550mm(61.024in)
Weight
400kg(881.8490lb)
Armcylinder
Cylinderbore∅ 200mm(7.874in)
Roddiameter
∅ 140mm(5.512in)
Maximumretractedlength
2588mm(101.890in)
Stroke1820mm(71.654in)
Weight
695kg(1532.2127lb)
Bucketcylinder
Cylinderbore∅ 165mm(6.496in)
Roddiameter
∅ 115mm(4.528in)
Maximumretractedlength
1972mm(77.638in)
Stroke1285mm(50.591in)
Weight
390kg(859.8028lb)
