Case WX148 - Monoboom version - transport dimension

INTRODUCTION
Monoboomversion-transportdimension
SMIL12WEX0084EA4
Frontbladeandrearstabilizers
Dipper
210024502950
A
2884mm(113.5in)3115mm(122.6in)3601mm(141.8in)
A1
2884mm(113.5in)3102mm(122.1in)3488mm(137.3in)
A2
2884mm(113.5in)3048mm(120.0in)3457mm(136.1in)
A3
2830mm(111.4in)2899mm(114.1in)3156mm(124.3in)
B
8012mm(315.4in)8058mm(317.2in)7967mm(313.7in)
B1
8012mm(315.4in)8058mm(317.2in)8015mm(315.6in)
B2
8012mm(315.4in)8056mm(317.2in)8023mm(315.9in)
B3
7984mm(314.3in)8017mm(315.6in)8075mm(317.9in)
C
3181mm(125.2in)
D
5752mm(226.5in)5798mm(228.3in)5707mm(224.7in)
D1
5752mm(226.5in)5798mm(228.3in)5755mm(226.6in)
D2
5752mm(226.5in)5796mm(228.2in)5763mm(226.9in)
D3
5724mm(225.4in)5757mm(226.7in)5815mm(228.9in)
E
2041mm(80.4in)
F
2260mm(89.0in)
1.Withbucketonly
2.Withquickcoupleronly
3.Withoutquickcouplerandbucket
Maximummachinewidth:2550mm(100.4in)
DimensionsmeasuredwithMITAS10.00-20twintyres.
47500167A31/01/2013
23
