INTRODUCTION
Dipper-2950mm(116.1in)
SMIL12WEX0080FA3
Bucketradius
1222mm(48.1in)
A
Maximumdiggingheight
10260mm(403.9in)
B
Maximumloadingheight
7810mm(307.5in)
C
Maximumdiggingdepth
5620mm(221.3in)
D
Maximumverticalwalldiggingdepth
4420mm(174.0in)
E
Maximumdiggingdepthofcutforlevelbottom5520mm(217.3in)
F
Maximumdiggingreach
9290mm(365.7in)
G
Maximumdiggingreachatgroundlevel
9100mm(358.3in)
H
Minimumswingradius
3050mm(120.1in)
K
Maximumloadingheight(dipperretracted)2800mm(110.2in)
Y
Maximumdiggingdepthbuckingmovement
2440mm(96.1in)
P
Maximumswingradiusofbuckingconnection3140mm(123.6in)
Q
Maximumheightofbuckingconnection9040mm(355.9in)
S
Maximumreachatgroundlevelofbuckingconnection7840mm(308.7in)
47500167A31/01/2013
29
