Case WX148 - Page 39

INTRODUCTION
Dipper-2950mm(116.1in)
SMIL12WEX0039FA6
Bucketradius
1222mm(48.1in)
A
Maximumdiggingheight
9070mm(357.1in)
B
Maximumloadingheight
6660mm(262.2in)
C
Maximumdiggingdepth
5600mm(220.5in)
D
Maximumverticalwalldiggingdepth
4560mm(179.5in)
E
Maximumdiggingdepthofcutforlevelbottom5420mm(213.4in)
F
Maximumdiggingreach
9000mm(354.3in)
G
Maximumdiggingreachatgroundlevel
8800mm(346.5in)
H
Minimumswingradius
3050mm(120.1in)
K
Maximumloadingheight(dipperretracted)2040mm(80.3in)
Y
Maximumdiggingdepthbuckingmovement
2440mm(96.1in)
P
Maximumswingradiusofbuckingconnection4660mm(183.5in)
Q
Maximumheightofbuckingconnection7900mm(311.0in)
S
Maximumreachatgroundlevelofbuckingconnection7540mm(296.9in)
47500167A31/01/2013
32
