General Guide
EN-5
English
• Pressing the pedals without adjusting the height adjustment screw can result in abnormal noise and/or damage to
the crosspiece.
See step 6 under “Assembling the Stand” on page EN-57.
Pedal Height Adjustment
Bottom
Front
Rear
Pedal connector
DC 24V terminal
USB port
LINE OUT R, L/MONO jacks
LINE IN R, L/MONO jacks MIDI OUT/IN
terminals
PHONES jacks
Power lamp
USB Flash Drive
Port
