Casio CT-S200 Manual

8.16 Portamento Control(54H)
Message Format: BnH 54H vvH
n: MIDI Channel Number
vv: Source Key Number
Receive Receipt of this message first stores the Source Note Number for the next note. When the next
Note On is received, the portamento effect is applied to the note using this Source Note Number as the
pitch start p oint and the Note On event key number as the end point. If there already is a note being
sounded by Source Note Number at this time, the new note on is not performed and the portamento
effect is applied to the pitch of the note being sounded. That is to say that legato play is performed.
8.17 Reverb Send Level (5BH)
Message Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the reverb send of the corresponding part.
8.18 RPN (Registered Parameter Number) LSB/MSB (64H,65H)
Message Format: BnH 64H llH (LSB)
BnH 65H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
8.18.1 Pitch Bend Sensitivity
Message Format: BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(00H - 0CH)
ll: LSB Value(Send:00H, Receive:Ignored)
Transmit Sent when Pitch Bend Range is changed. (CT-S300)
Receive Receipt changes Bend Range of the corresponding part.
11

Casio CT-S200 Specifications

General

Keyboard	61 keys
Polyphony	48 notes
Tones	400 built-in tones
Rhythms	77 built-in rhythms
Speakers	2 x 2.5W
Dance Music Mode	Yes
Lesson Function	Yes
Touch Response	No
Song Bank	60 built-in songs
Metronome	Yes
Transpose	Yes
Connectivity	Audio In (3.5mm Stereo Mini Jack), USB to host
Power Supply	AC adapter or 6 AA batteries
Weight	3.3 kg (without batteries)
Dimensions	93.0 x 25.6 x 7.3 cm
App Connectivity	Chordana Play for Piano
Effects	Reverb
Tuning	A4 = 415.5 to 465.9 Hz
MIDI	Yes
Audio Input	3.5mm stereo mini jack
Audio Output	3.5mm stereo mini jack
Amplifiers	2.5W + 2.5W
