Casio CT-X800 User Manual

Controlling the Keyboard Sounds
EN-14
1. Select the tone for the right side range (page
EN-12).
Press bl TONE and then use the ct number keys, and
the dk [–] and [+] keys to select the tone you want.
Example: 255 FLUTE
2. Press co SPLIT.
3. Use the ct number keys, and the dk [–] and [+]
keys to select the left side range tone you
want.
Example: 044 VIBRAPHONE 1
4. Play something on the keyboard.
This will sound the tones assigned to the left and right
side ranges of the keyboard.
• Pressing co SPLIT again will turn split off.
• If you turn on both layer and split, layering will be applied to
the right side range of the keyboard only.
1. Keep co SPLIT depressed until you finish step
2 of this procedure.
This will cause the key name at the currently set split
point to appear on the display.
2. Press the keyboard key where you want the
split point to be.
The key you press will become the lowest note of the
right side range of the split keyboard.
Example: Setting middle C (C4) as the split point.
To split the keyboard between two different
tones
F l u t e
Lights
V i b e s 1
To change the split point
VIBRAPHONE 1 FLUTE
F3
Split point
C4
Key name
CTX800-ES-1A.indd 16 2017/11/28 10:19:08

Casio CT-X800 Specifications

General

RMS rated power	2.5 W
Speaker diameter	12 mm
Number of speakers	2
USB connector type	USB Type-A, USB Type-B
Product color	Black
Tuning frequency	415.5 - 465.9 Hz
Demo songs quantity	1
Preset programs quantity	160
Keys quantity	61 keys
Power source type	DC

Weight and Dimensions

Depth	350 mm
Width	948 mm
Height	109 mm
Weight	4400 g
