Casio CT-X800 User Manual

EN-5
General Guide
■ Back
1 P(Power) button ☞EN-9
2 VOLUME knob ☞EN-9
3 INTRO, REPEAT button ☞EN-20, 31
4 NORMAL FILL-IN, A-B button ☞EN-30
5 VAR. FILL-IN, sREW button ☞EN-19, 30
6 ENDING/SYNCHRO START, dFF button
☞EN-19, 31
7 SYNCHRO STOP, kPAUSE button ☞EN-19, 32
8 START/STOP, PLAY/STOP button ☞EN-10, 27
9 [ACCOMP], PART SELECT, $MUSIC PRESET
button ☞EN-22, 27, 33
bk PIANO/ORGAN, $TOUCH button ☞EN-10, 12
bl TONE button ☞EN-12
bm RHYTHM button ☞EN-27
bn SONG BANK button ☞EN-19
bo CATEGORY button ☞EN-7
bp RECORD/STOP button ☞EN-39
bq CHORD MODE, $CHORD BOOK button
☞EN-35
br A.HAR./ARPEG., $TYPE button ☞EN-33, 34
bs EASY MODE, BANK, $FREEZE button
☞EN-22, 37, 38
bt Area1, LISTEN button ☞EN-23, 37
ck Area2, WATCH button ☞EN-23, 37
cl Area3, REMEMBER button ☞EN-24, 37
cm Area4, PHRASE button ☞EN-24, 37
cn STORE button ☞EN-37
co SPLIT, $POINT button ☞EN-14
cp LAYER, $OCTAVE button ☞EN-13, 17
cq METRONOME, $BEAT button ☞EN-10
cr TEMPO/TAP button ☞EN-11
cs FUNCTION button ☞EN-43
ct Number keys ☞EN-6
dk [–] and [+] keys ☞EN-6
dl Speakers
dm Song Bank list
dn Rhythm list
do Tone list
dp Display
dq Tray
• The tray is angled slightly. Take care so items placed on
it do not slide off.
• Do not place cups or any other liquid containers on the
tray.
dr PITCH BEND wheel ☞EN-18
ds CHORD root names ☞EN-28
dt Percussion instrument list ☞EN-12
elek
em en eo ep
ek USB flash drive ☞EN-48
el USB port ☞EN-53
em PEDAL jack ☞EN-16
en AUDIO IN jack ☞EN-55
eo DC 9.5V terminal ☞EN-8
ep PHONES/OUTPUT jack ☞EN-9, 55
CTX800-ES-1A.indd 7 2017/11/28 10:19:07

Casio CT-X800 Specifications

General

RMS rated power	2.5 W
Speaker diameter	12 mm
Number of speakers	2
USB connector type	USB Type-A, USB Type-B
Product color	Black
Tuning frequency	415.5 - 465.9 Hz
Demo songs quantity	1
Preset programs quantity	160
Keys quantity	61 keys
Power source type	DC

Weight and Dimensions

Depth	350 mm
Width	948 mm
Height	109 mm
Weight	4400 g
