Reference
E-153
• Design and specifications are subject to change without notice.
Pitch Bend Wheel
Pitch Bend Range 0 to 12 semitones
Memory Cards
Supported Memory Cards SD or SDHC memory cards, 2GB to 32GB
Functions SMF playback, file storage, file recall, file delete, card format
Inputs/Outputs
USB port TYPE B
Sustain/Assignable jack Standard jack (sustain, sostenuto, soft, start/stop)
Phones jack Stereo standard jack
Line Out R, L/MONO jacks Standard jack × 2
Output Impedance: 2.3k, Output Voltage: 1.5V (RMS) MAX
Audio In jack Stereo mini jack
Input Impedance: 9k, Input Sensitivity: 200mV
Inst In Jack Standard jack
Input Impedance: 9k, Input Sensitivity: 200mV
Mic In jack Standard jack (connect a dynamic microphone only)
Input Impedance: 3k, Input Sensitivity: 10mV
Power Jack 12V DC
Power Supply 2-way
Batteries 6 D-size zinc-carbon batteries or alkaline batteries
Battery Life Approximately 4 hours continuous operation on alkaline batteries
AC Adaptor AD-A12150LW
Auto Power Off Approximately 6 minutes after last key operation during battery use,
approximately 4 hours after last key operation during AC adaptor use. Auto Power Off can be
disabled.
Speakers 12 cm × 2 + 3 cm × 2 (Output: 7.0W + 7.0W)
Power Consumption 12V = 18W
Dimensions CTK-7000: 94.5 × 37.8 × 13.2 cm (37
1
/4 × 14
7
/8 × 5
3
/16 inch)
WK-7500: 118.7 × 39.9 × 14.9 cm (46
3
/4 × 15
3
/4 × 5
7
/8 inch)
Weight CTK-7000: Approximately 6.8kg (15.0 lbs) (without batteries)
WK-7500: Approximately 8.9kg (19.6 lbs) (without batteries)
