DT-X200 Hardware Manual P.16
Item Specification Remark
Terminal layout
Th
e
l
ayout
i
s v
i
ewe
d
when The terminal is
placed with The display
panel upward.
Terminal table Refer to ＊1
microSD Compatible with SDHC
Extension Port
Speaker Monaural
Microphone Monaural
Excluding the DT-X8
Power/Signal terminals
1
2
3
4
56
Pin assignment
1
＊１ Pin assignment table
Pin no. Signal Description Direction
1 V CRADLE Power supply / Charge to the terminal -
2D
＋
USB D
＋
IN/OUT
3D
－
USB D
－
IN/OUT
4 USB_ID Switch-over between USB host and USB client IN
5 V BUS Power from USB cradle -
6GND GND -
