5. Unsolder four lead wires.
Note:
Make sure not to damage the lead wire when assembling the rear panel.
Fix the lead wire first when assembling the product.
The rubber key is fixed by the double-sided tape on the rear panel.
Rubber key
■ Removing the LCD
4. Remove one screw, and then the spacer fixing the LCD unit.
Lead wire
Spacer
Black wire
Red wire
Red wire
Black wire
Screws (S3)
