Casio I/O-PB-11 Service Manual

— 5 —
Connect the C-In line
connector as shown below:
C-In line cable
Cable fixing plate
Part of copper tape
Cable supporter
Connect to C-In line connector.
1. Structure
Conductor Material: Tin plated mild copper twist
Cross section area: 0.5mm
2
Construction: 20 pieces/0.18 mm
O.D. 0.95 mm
Insulation Material: Polyethylene
Thickness 0.3 mm
Sheath Material: PVC
Thickness 1.3 mm
Finished O.D.: 6.0 ~6.5 mm
Approx. weight: 55 kg/km
2. Properties (20°C)
Maximum conductor resistance 38.7 Ω/km
Minimum insulation resistance 10 kMΩ•km
Electric strength AC350 V/1 minute
Electrostatic capacity (Standard) 75 nF/km
6) C-In line cable specification
