LK-120
– 9 –
Turn over the panel unit.A-3.
Unsolder two battery lead wires.A-4.
Unsolder two FFCs.A-5.
Lead wire (Red)
Lead wire (Black)
FFC
(
M800-KYA2
)
FFC (M821-LDA2)
Remove the panel unit.A-6.
M821-MDA1 PCBM820-PSA1 PCB
