Casio LK-125 Service Manual & Parts Guide

LK-125
–25–
1: LK-125_DI
2: LK-125_EU
3: LK-125_UK
4: LK-125_US
1234
N Item Code No. Parts Name Specification
Price
Code
R Remarks
Q'ty
PANEL UNIT
17 10371166 PLATE/DISPLAY RJM510316-003V02 1111 X
18 10301435 KNOB RJM503803-009V01 2222 X
19 69095890 CONTACT/SLIDE SWITCH CSB-12D 2222 X
N 20 10417026 FABRIC TAPE RJM511849-001V01 1111 X
N 21 10417025 FABRIC TAPE RJM511833-001V01 1111 X
22 10272509 LCD SDT-M4396-RP-0 1111 X
23 10366853 RUBBER CONNECTOR RJM510317-001V01 2222 X
24 10366689 RUBBER KEY/A RJM510262-002V01 1111 X
25 10366690 RUBBER KEY/B RJM510264-002V01 1111 X
26 10366692 RUBBER KEY/C RJM510282-002V01 1111 X
27 10366693 RUBBER KEY/D RJM510283-002V01 1111 X
28 10366694 RUBBER KEY/E RJM510284-002V01 1111 X
29 10366695 RUBBER KEY/F RJM510285-001V01 1111 X
30 10264808 SPEAKER C10J01A 2222 X
N 31 10377336 PANEL RJM510265-005V01 1111 X
32 10366841 SIDE PANEL/LEFT RJM510267-001V01 1111 X
33 10366842 SIDE PANEL/RIGHT RJM510268-001V01 1111 X
MAIN CASE UNIT
34 10368209 CASE UNIT/MAIN TK-RJM510380*001 1111 X
35 10301471 FELT/LOWER RJM508593-001V01 1111 X
36 10317116 FELT/DAMPER/KEYBOARD RJM509138-001V01 1111 X
37 10205015 FELT/UPPER M440342-001V02 1111 X
38 10284332 BRACKET/for stand M440866-001V02 2222 X
39 69271080 BATTERY SPRING/(+) M440112-1 1111 X
40 10274835 BATTERY SPRING/(-) M440002-001V02 1111 X
41 69271060 BATTERY SPRING-470A M440676-1 2222 X
42 69271070 BATTERY SPRING-470B M440677-1 3333 X
43 69226920 RUBBER FOOT M41361-6 4444 X
44 10243428 COVER ASSY/BATTERY TK-M340884*020 1111 X
45 10329837 LOWER COVER-A RJM508655-001V03 1111 X
46 10329838 LOWER COVER-B RJM508656-001V03 1111 X
47 10329839 LOWER COVER-C RJM508657-001V03 1111 X
N 48 10377332 RATING LABEL RJM504373-042V02 1111 X
ACCESSORIES
- 10366857 MUSIC STAND RJM510426-001V01 1111 C
