E
14
2. Check the condition of the tape.
• Make sure the tip of the tape is not bent. If it is, use scissors to cut off the bent part.
Tape
Pull out approximately 11 cm (4.3 in), measured
from the center of the roll to the tip of the tape.
3. Place the tape into the printer.
Run the tape over the rubber roller (see fi gure below). Make sure the tape is seated
securely onto the bearing.
• When loading tape, take care not to touch the cutter. Touching the cutter can cause
fi nger cuts.
• The printer head becomes hot during printing. Do not touch the printer head when
loading tape.
Important!
• Never try to push tape back in.
• Do not pull on the tape with excessive force. Doing so will lead to malfunction of
the printer.
• Note that normal printing may not be possible at the leading edge of a new roll of
tape.
• Incorrectly loading the tape can cause malfunction of the printer.
Cutter
Printer head
Bearing
Tape Rubber roller
