— 4 —
3-2.
BLOCK DIAGRAM
CPU
uPD78052GC-093-3B9
Head Drive Circuit
Reset Circuit
Keynoard
Mode key
Power Supply Circuit
HA.A ~ HD.H
PRINTER
M-190G
DISPLAY CONTROL
uPD16312GB-3B4
CUSTOMER DISPLAY
SH1019A
MAIN DISPLAY
SH101MA
DI,DO,CLK,STB
Segment & Digit data
A8 ~ A15
KC0 ~ KC4
Select address
AD0 ~ AD7
AD0 ~ AD5
AD0 ~ AD7
AD0 ~ AD7
ROM
RAM
A8 ~ A11
A8 ~ A15
A0 ~ A7
A0 ~ A7
ASTB
enable
BUS Select Circuit
KEY Circuit
FD,RP,MD,DP
MAIN PCB E248-1
5
7
Table of Contents
Service Manual
2
Default Chapter
2
Table of Contents
2
1 Specifications
3
2 Initialize (Mac) Operation
4
3 Block Diagram
5
Pcb Connection
5
Block Diagram
6
4 Disassembly
7
5 Circuit Explanation
9
Power Supply Circuit
9
CPU (Upd78052Gc-159-3B9)
10
Display Controller (Upd16312Gb-3B4)
12
Initilize IC (Reset Circuit)
13
Power down Detection Circuit (PWD)
13
Address Latch Circuit
13
RAM / ROM Bank Selection Circuit
14
Head Drive Circuit for Printer
15
Power Supply Circuit for Display
16
6 Diagnostic Operation
17
To Start the Diagnostic Program
17
Check Item
17
Operation of each Test
17
To Exit the Diagnostic Test
22
7 Error Code List
23
Operation Error Code
23
System Lock Code
24
8 IC Data
25
9 Pcb Layout
28
10 Circuit Diagram
29
Model : Pcr-365A
44
11 Parts List
44
Exploded View
45
Main PCB Block E248-1 Ass'y
47
Button Block
48
Customer Display Block E248-E2-2
48
Main Display Block E248-E2-1
48
Power Supply Block
49
Lower Case Block
50
Others
50
Printer Block
50
Upper Case Block
50
Cash Drawer (DL-1324)
51
Printer (M-190G)
53
