Casio PRIVIA PX-130 User Manual

English
Playing with Different Tones
E-9
Use the following procedure to layer two tones, so they
sound at the same time.
When specifying two tones for layering, first tone you
select will be the main tone, while the second tone will
be the layered tone.
1. While holding down the FUNCTION button,
hold down the keyboard key for the main tone
as you press the keyboard key for the layered
tone.
Example: To layer HARPSICHORD and STRINGS 1
2. To unlayer the keyboard, select another tone
by pressing the GRAND PIANO button or by
using the procedure under “Selecting and
Playing a Tone” (page E-7).
NOTE
• You also can layer piano tones by holding down one
of the GRAND PIANO buttons (MODERN or
CLASSIC) as you press the ELEC PIANO button.
• You cannot layer the BASS 1 or BASS 2 tone with
another tone.
• You cannot perform the layer operation when
recording to Track 2.
To adjust the volume balance between
two layered tones
1. While holding down the FUNCTION button,
use the keyboard keys shown below to adjust
the volume of the layered tones.
• To return the volume setting to its initial default, hold
down the FUNCTION button and press both of the
keys at the same time.
Layering Two Tones
HARPSICHORD
STRINGS 1
C1 C2 C3 C4 C5 C6 C7 C8
Initial default (Center)
Volume of the main tone
(First tone you selected)
Volume of the layered tone
(Second tone you selected)

Casio PRIVIA PX-130 Specifications

General

Polyphony	128 notes
Tones	16
Speakers	12cm x 2
Amplifier	8W + 8W
Weight	11.2 kg
Digital Effects	Reverb (4 types), Chorus (4 types)
Built-in Songs	60
Recorder	2 tracks, 1 song
Touch Sensitivity	3 levels, Off
Lesson Function	Part On/Off
Metronome	Yes
Power Consumption	18W
Keyboard	88 keys, weighted hammer action
Dimensions	1, 322 x 286 x 135 mm
Terminals	USB, MIDI, Line Out, Headphones
Transpose	-12 to +12 semitones
Tuning Control	A4 = 415.5 Hz to 465.9 Hz
Pedals	SP-3
Power Supply	AC Adapter AD-A12150LW
Included Accessories	AC adaptor, SP-3 pedal, music stand
Connectors	USB, MIDI, Headphones
