General Guide
E-3
CAUTION
• Make sure that the cover is fully open whenever you are playing on the keyboard. A partially open cover can suddenly close
unexpectedly and pinch your fingers.
NOTE
• The names shown here are always indicated in bold when they appear within the text of this manual.
1-1 Power supply box
1
-2 AC power jack
2 Pedal connector
3 MIDI OUT/IN terminals
4 USB port
5 Speaker connector
6 LINE OUT R, L/MONO jacks
7 PHONES jack
8 Display
9 TONE lamp
bk SONG lamp
bl – (T
TT
T/NO) button, + (S
SS
S/YES) button
bm TONE/SONG button
bn SONG PLAY/STOP button
bo TEMPO/SETTING button
bp PART/TRACK button
L/1 lamp
R/2 lamp
bq CARD button
br RECORDER button
PLAY lamp, REC lamp
bs GRAND PIANO button
bt METRONOME button
ck Power lamp
cl POWER button
cm VOLUME controller
cn SD CARD SLOT
