E-13
General Guide
Bottom
g
PEDAL connector
g
Rear Panel
h
USB port
i
DAMPER PEDAL jack
j
SOFT/SOSTENUTO PEDAL jack
NOTE
• Display examples shown in this User’s Guide are intended for illustrative purposes only. The actual text and values that
appear on the display may differ from the examples shown in this User’s Guide.
• Due to LCD element characteristics, display contrast changes depending on the angle from which you view it. The initial
default contrast setting is one that allows easy viewing for a musician seated directly in front of the display. You can also
adjust the contrast to the level that suits your particular needs. For more information, see page E-71.
