General Guide
1.P (Power) button 9. ELEC. PIANO button
2.Volume knob 10. PHONES jacks
3.FUNCTION button 11. USB port
4.SOUND MODE button 12. DAMPER PEDAL jack
5.METRONOME button 13. PEDAL UNIT jack
6. button
14. AUDIO IN jack
7. ● (REC) button 15. LINE OUT R, L/MONO jacks
8.GRAND PIANO button 16. DC 12V terminal
■ Preparing the Music Stand
■ Keyboard note names and pitches The keyboard note names and pitches used in these instructions follow the international standard.
Middle C is C4, the lowest C is C1, and the highest C is C8. The illustration below shows keyboard key note names from C4 through C5.
Keyboard Function List
Function settings can be configured by holding down a touch button as you press a keyboard key. For more information refer to the Keyboard
Function List available from the CASIO website.
■ GRAND PIANO Button + Keyboard Key *
To Next Page
