Casio SE-S400 Service Manual

– 39 –
SE-S400/SE-S800/PCR-T500/PCR-T520/SE-C450
SE-S3000/SE-S900/PCR-T2300/PCR-T2400/SE-C3500
7-1. EXPLODED VIEW (BODY)
SE-S3000/PCR-T2300/
PCR-T2400/SE-C3500/
SE-S900
SE-S400/PCR-T500/
PCR-T520/SE-C450/
SE-S800
7
21
11
16
5
1
2
9
13 13
S2
14
S2
12
12
24
S1
25
33
Washer
S1
S1
S4
S1
S5
23
S3
S3
S5
22-3
22-4
22-2
19
17
20
4
27
28
26
30
6
8
31
32
10-2
10-1 10-3
15
22-1
18
S4
S1
S1
29
S1
34 35
34-1
35-3
35-4
35-5
35-2
35-1
34-2
34-4
34-3
34-6
34-6
34-5
34-5
KEY BLOCK
3
22
42
S1
10
S1
35-6
35-6
35-7
35-7

Casio SE-S400 Specifications

General

Clerk lock	Yes
Types of payment	Cash
Number of Price Look-Up codes (PLUs)	3000 PLUs
Supported paper width	58 mm
Display number of lines	10 lines
Display number of characters	26
Second display number of characters	20
RS-232 ports	2
Power source	AC
AC input voltage	100-240 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	220 mm
